Auto screw tightening - High-end Semi Auto

Contact

SKU: Status: Out of stock

Feature:

Single/double head optional. Screw feeding automatically. Screw capture by vacuum.
Real-time monitoring and controlling all parametter of a screw tightening.
X-Y axis controller combine with camera. Increase the position accuracy up to +/- 5um.
UPH up to 2.5s / 1 screw.

Screw tightening head:

Position controller:

X-Y axis control combine with camera. Increase the position accuracy up to +/- 5um.
Tilt/rotate/flip stage includable, support ability to drive screw to multiple surface of product.
Support 20 screw position for each recipe.

UPH up to 2.5s / 1 screw.

Traceability available make it more convenience for the production management.

Available to upgrade to full automation or combine to current automation line.

Specification:

Description	Detail
Machine Size (Width x Depth x Height) (mm)	One Head:800x1000x1900
Machine Size (Width x Depth x Height) (mm)	Double Head:1000x1000x1900
Stage	Slide table / Rotary table / Turn table optional
Working Area (mm)	X Y Z = 300 x300 x150
Repeatability	From +/-30um to +/- 5um optional
Load	Up to 20 Kg
Number of head	Single / double optional
Screw Feeding Method	Pick & Place / Blow-Shoot optional
Screw Size	Threads: M2 ~ M5
Screw Size	Length: Up to 12mm
Expansion	Handy Code Reading
	Alignment and Inspection Function
	Torque and Height Traceability
